| Item | Unit | Specification |
|---|---|---|
| Engine | ||
| Type | - | 6BT5.9-C130 |
| Rated power | (kW/r/min) | 97/2200 |
| Thrust-Pull | ||
| Max thrust-pull force | (kN) | 180 |
| Thrust-pull speed | (m/min) | 23 |
| Rotation | ||
| Torque | (N·m) | 6000 |
| Max spindle speed | (r/min) | 150 |
| Mud pump | ||
| Max Flow rate | (L/min) | 250 |
| Max pressure | (MPa) | 8 |
| Drill Pipe & Others | ||
| Pipe | (mm×m) | φ60×3 |
| Max backreamer diameter | (mm) | φ600 |
| Max inclination angle | (°) | 22 |
| Weight | (t) | 8.5 |
| Dimension | (mm) | 6500×2270×2340 |
| Remark | - | Optional: Mud antifreeze, Mud Cleaning |
